Patio · Gliding
2-Panel Gliding Patio Door
A sliding door built to move the same way on day one and at year twenty.
In stock at Lowe's, in store and online. Twenty-four configurations across two sizes, four glass styles, and both handings.
Where to buyFull specification
- ENERGY STAR certified in all four US climate zones, 20 of 24 configurations.1
- Lifetime warranty on frames, astragals and panels, for the original owner.
- Full composite frame, solid core, holds its shape through a wet season and a dry one.
What does a sliding door sound like after ten years?
Engineered for the decade, not the showroom.
On most doors: a drag at the leading edge, a lift to clear the track, a handle that has to be worked rather than pulled.
None of that is inevitable. Two panels ride on rollers built to carry the full weight of the glass indefinitely, sealed by a compression strip that holds tighter with use, inside a frame that does not warp with the weather that moves through it.
Two panels, two hundred fifty pounds each
A track engineered to take the weight, indefinitely.
The difference between a door that still tracks straight after years of use, and one that starts to drag at the leading edge.
Certified performance
Tested together, frame and glazing, not claimed apart
Figures below are for the 20 standard configurations. The four blinds-between-glass configurations carry their own thermal profile, set out honestly under Specifications.
0.26
U-Factor1The rate of heat loss through the door. Lower means less heat escapes.
0.18
Solar heat gain1Lower means less solar heat enters through the glass in summer.
DP50
Gold label rating2Wind and structural load the assembly withstands, across the line, every glass style.
0.41
Visible transmittance1,4The share of visible light the glass lets through into the room.
01 · The carriage
Built to carry the same weight at year twenty
Two hundred fifty pounds a panel, on a track engineered to take it indefinitely.
Each panel rides on stainless steel tandem rollers, two wheels per carriage rather than one, spreading the load instead of concentrating it at a single wheel. That is the difference between a door that still tracks straight after years of use and one that drags at the leading edge.
The handle set and lockset are fitted at the factory, so there is nothing left to source or bore.
02 · The seal
A seal that holds tighter with use
Most weatherstripping wears thin. This is built to do the opposite.
Compression weatherstripping closes by being squeezed against the frame, not brushed past it, so each close presses the seal tighter rather than wearing it down.
Behind it, a polyurethane foam core; around the whole unit, a full composite frame that keeps its shape through a wet season and a dry one, without swelling or shrinking.
03 · The glass
Where performance splits by glass style
Twenty of twenty-four configurations meet ENERGY STAR in every US zone. Four do not.
The difference is the glass, not the frame. Clear, simulated divided light and grilles-between-glass carry a 0.26 U-Factor and 0.18 SHGC, certified in all four zones. The four blinds-between-glass configurations carry a 0.30 U-Factor and 0.35 SHGC, and are not certified.
Both figures come from the same testing standard; they simply describe two different glass assemblies honestly.
The same door, four readings
Choose the glass, not the door
Clear, divided light and grilles share one certified performance. Blinds-between-glass adds a sealed shade, with its own figures, stated in full.
Grilles between the glass
A visible grid set inside the sealed unit, with no bar to clean.
Simulated divided light
Surface-mounted bars for a deeper, more traditional profile.
Clear glass
No pattern at all, two full-height panels of uninterrupted glass.
Blinds between the glass
A shade sealed inside the glass cavity, nothing to dust, its own thermal figures.
In the crate
It arrives prehung, ready for the opening
Set in a jamb 5.75 inches deep; each panel weighs 250 pounds fully glazed. What is ordered is what is installed.
- 01Both panels, glazed and hung in the frame
- 02White handle set & lockset, factory-fitted
- 03Compression weatherstripping, installed
- 04Stainless tandem rollers, installed on the track
Not in the crate: brickmould, a screen and a pet door are not part of the standard unit. If the opening calls for any of them, they are specified separately.
The complete record
Specifications
Twenty-four configurations across two sizes, four glass styles, and both handings. Two thermal profiles, neither hidden inside an average.
Construction
Performance & configuration
- 1ENERGY STAR certified in the Northern, North-Central, South-Central and Southern zones for 20 of 24 configurations (clear, SDL, grilles) at U-Factor 0.26, SHGC 0.18. The four blinds-between-glass configurations (0.30 / 0.35) are not certified in any zone.
- 2Structural DP50 Gold label 10657, under the AAMA / WDMA / CSA standard; thermal performance rated separately by NFRC, Gold NAMI label 20617. Two distinct programmes.
- 4Visible Transmittance 0.41 (standard) / 0.39 (blinds) is drawn from a source document pending a brand-correct reissue, and is not yet confirmed for publication.
Backed, tier by tier
Coverage stated in full, glass by glass
Shown for an owner-occupied, single-family home.3 Glass coverage differs by configuration.
Coverage is for parts, not labour. Claims are raised through the retailer the door was purchased from, not the manufacturer. Coverage is void above 4,000 feet elevation, and may be void if the factory finish is repainted below LRV 57.3
Always within reach
One door. Twenty-four configurations. One retailer.
In store and online at Lowe's, no special order, no regional variant, no wait.
Where to buy
